Geology-Customized Thread Drill Bits – High-Speed Drilling for Global Mines | Jiufu

As a professional manufacturer integrating R&D, production, and global export, Hebei Jiufu Industrial and Mining Parts Co., Ltd. presents the Geology-Customized Thread Drill Bits—engineered to solve drilling challenges across diverse global geologies. Trusted by projects in 150+ countries, from South African hard granite mines to Russian permafrost exploration, these drill bits combine premium materials, geology-specific designs, and global standard compliance to deliver fast penetration, long service life, and cost-effective performance.

CONTACT NOW

Details

Detailed Product Content

1. Core Product Characteristics

1.1 Premium Materials & Precision Craftsmanship

Crafted with a high-grade H13 alloy steel body (heat-treated at 1100℃ for superior toughness) and YG11C/YG13C tungsten carbide tips (density ≥14.9g/cm³), our thread drill bits withstand extreme drilling conditions without deformation or tip breakage. Key craftsmanship highlights:

Precision CNC machining ensures consistent thread pitch and tip angle (118°/135° optional), reducing drilling resistance.
Carbide tips are brazed with high-temperature solder (≥850℃) for firm bonding—no tip detachment during high-speed drilling.
Standard outer diameters: 8mm-50mm; customizable range: 5mm-80mm to match diverse hole size requirements.
Available in three core types: Cross-cut (soft rock), Ball-tooth (hard rock), and Clay-specific (sticky soil/soft sedimentary rock).

1.2 Global Standard Compliance & Durability

The product is ISO9001 certified and complies with international standards including ISO 6411, ASTM E250, EU CE, Russian GOST, and Australian AS 2341. To adapt to harsh environments:

Surface treatment options: Hot-dip galvanizing (430-600g/㎡) for humid mines; epoxy coating for coastal/salt spray regions (corrosion resistance meets ISO 12944 C5-M).
Working temperature range: -40℃ to 120℃, suitable for permafrost, high-temperature mines, and tropical exploration projects.
Service life: ≥500 drilling meters for hard rock; ≥800 drilling meters for soft rock—40% longer than industry average.

2. Global Geological Adaptation Scenarios

Our thread drill bits are customized to match unique geological conditions worldwide, eliminating "one-size-fits-all" inefficiency:

2.1 Hard Rock (South Africa, Australia, Canada)

Drill bit type: Ball-tooth with YG13C carbide tips (HRC ≥65)
Key advantages: Reinforced tip structure resists impact; 135° tip angle reduces penetration resistance in granite/quartzite.
Application cases: South African gold mines, Australian iron ore exploration—penetration speed 30% faster than standard bits.

2.2 Soft Rock/Sedimentary Rock (Southeast Asia, Middle East)

Drill bit type: Cross-cut with sharp YG11C carbide edges
Key advantages: Wide cutting surface reduces energy loss; spiral thread design enhances chip removal in sandstone/siltstone.
Application cases: Vietnam highway geological surveys, Indonesian coal mine drilling—completes 10km drilling 25% faster.

2.3 Permafrost Rock (Siberia, Northern Canada)

Drill bit type: Low-temperature resistant alloy body + YG11C tips
Key advantages: Alloy body withstands -40℃ cold without brittleness; anti-freezing coolant compatibility.
Application cases: Russian frozen rock exploration—stable operation in extreme cold with no performance loss.

2.4 Corrosive/Coastal Environments (Australia, Indonesia)

Drill bit type: Epoxy-coated body + corrosion-resistant carbide tips
Key advantages: Epoxy coating prevents salt spray/acidic water erosion; sealed brazed joints avoid moisture damage.
Application cases: Australian coastal sandstone projects, Indonesian port infrastructure drilling—service life extended by 50%.

3. Technical Advantages

3.1 High Penetration Efficiency

Spiral thread design + optimized tip angle reduces drilling resistance by 25%, cutting project time significantly.
High rotational speed compatibility (800-2000 rpm) adapts to handheld/automated rock drills (Atlas Copco, Sandvik, and local brands).

3.2 Superior Wear Resistance

Tungsten carbide tips with 30% higher density than industry standards—resist wear in abrasive rock.
Heat-treated H13 alloy body enhances toughness, preventing breakage in high-vibration drilling.

3.3 Universal Compatibility

Fits global standard rock drill interfaces, eliminating equipment mismatch for cross-border projects.
No special adapters required—reduces on-site training and tool replacement costs.

3.4 Cost-Effective Performance

Long service life reduces drill bit replacement frequency by 40%.
Customized design avoids over-engineering, matching performance to project needs without unnecessary costs.

4. Step-by-Step Installation & Maintenance Guide (with Regional Adaptation)

4.1 Pre-Installation Preparation

Tools Required: Global standard rock drill (handheld/automated), compatible adapter, coolant (mineral oil for hard rock; water-based for soft rock), caliper, cleaning brush, anti-rust lubricant.
Geology Check: Confirm rock type/hardness and select matching drill bit (e.g., ball-tooth for hard rock, cross-cut for soft rock).
Drill Bit Inspection: Check for carbide tip damage, thread wear, and coating integrity—replace defective bits before use.

4.2 Standard Installation Steps

Attach the drill bit to the rock drill using a compatible adapter—tighten firmly to avoid vibration-induced loosening.
Apply appropriate coolant: Mineral oil for hard rock (reduces tip overheating); water-based coolant for soft rock (controls dust).
Adjust drilling parameters: 800-1200 rpm for hard rock; 1500-2000 rpm for soft rock—avoid excessive force to prevent tip damage.
Drill vertically (or at designed angle) with steady pressure—stop periodically to clear chips and cool the bit.
Post-drilling: Clean the bit with a brush to remove residual chips; inspect tip wear (replace if wear exceeds 3mm).

4.3 Regional Maintenance Precautions

Hard Rock Regions (South Africa/Australia): Use high-pressure mineral oil coolant; check tip wear every 50 drilling meters. Store bits in dry, shockproof containers.
Soft Rock Regions (Southeast Asia/Middle East): Clean chip grooves regularly to prevent clogging; use water-based coolant to avoid dust pollution.
Permafrost Regions (Siberia): Pre-heat the drill bit to 5-10℃ before use; use anti-freezing coolant. Avoid long idle time to prevent re-freezing.
Coastal Regions (Australia/Indonesia): Rinse bits with fresh water after use to remove salt residue; apply anti-rust lubricant before storage.

5. Geology-Customization Service

We offer end-to-end customization to meet unique project requirements—no matter the geology or location:

5.1 Customizable Parameters

Drill bit type: Ball-tooth, cross-cut, clay-specific, or custom tooth shape.
Dimensions: Outer diameter (5mm-80mm), length (100mm-500mm), tip angle (90°-150°).
Materials: Carbide grade (YG8/YG11C/YG13C), alloy body (H13/low-temperature resistant alloy).
Surface treatment: Hot-dip galvanizing thickness, epoxy coating color.
Packaging: Custom logo, moisture-proof cartons, palletization for long-distance shipping.

5.2 Customization Process

Provide your requirements: Geological report (rock type/hardness) + project specifications (hole size, drilling equipment).
Receive a customized solution + quote within 24 hours.
Confirm sample (free for orders over 1000pcs) for performance testing.
Mass production (ISO9001 certified) with strict quality control.
Global delivery with tracking and on-site technical support (if needed).

6. Global Shipping & After-Sales Support

6.1 Shipping Terms

Support FOB (Tianjin Port), CIF, CFR, DDU, and DDP.
Delivery time: 7-30 days to 150+ countries (Europe: 12 days, Africa: 18 days, Southeast Asia: 10 days, North America: 15 days).
Packaging: Shockproof foam + corrugated cartons to protect drill bits during long-distance shipping.

6.2 Payment Methods

Accept TT, L/C, Trade Assurance, Credit Card, and Western Union—flexible options for global clients.

6.3 After-Sales Service

24/7 technical support via WhatsApp/email (multilingual: English, Spanish, Russian, Vietnamese).
Warranty: Free replacement for defective products within 6 months (covers material/ craftsmanship issues).
On-site support: Drilling guidance and team training for orders over 5000pcs.
Lifetime consultation: Expert advice on geology-drill bit matching and performance optimization.

7. Quality Control

Jiufu adheres to strict quality management standards, with a comprehensive inspection process from raw material to shipment:

Raw material inspection: Chemical composition test for H13 alloy steel; density/hardness test for tungsten carbide tips.
Production process control: Heat treatment temperature monitoring (1100℃ ±10℃); tip angle precision measurement (tolerance ±0.5°).
Performance testing: Penetration speed test on simulated rock; wear resistance test; corrosion resistance test (salt spray ≥500 hours).
Packaging inspection: Shockproof and moisture-proof verification to prevent damage during shipping.

8. Project Cases

South African Gold Mine: Supplied 5000pcs 32mm ball-tooth drill bits (YG13C) for granite drilling—penetration speed 35% faster than local products; service life reached 600 drilling meters.
Vietnam Highway Survey: Delivered 3000pcs 25mm cross-cut drill bits for soft sedimentary rock—completed 10km drilling in 15 days with no tip damage.
Russian Permafrost Exploration: Provided 2000pcs low-temperature thread drill bits (-40℃ rated) for frozen rock projects—stable operation in extreme cold with zero failures.
Australian Coastal Project: Delivered 1500pcs epoxy-coated drill bits for sandstone drilling—resisted salt spray corrosion for 3 years with no performance decline.

Why Choose Jiufu’s Geology-Customized Thread Drill Bits?

With annual sales of 50 million US dollars and 12,000 tons of products exported globally, Jiufu combines decades of drilling tool expertise with a customer-centric approach. Our thread drill bits stand out for:

Geological customization that solves region-specific drilling challenges.
Global standard compliance that avoids cross-border project rework.
Long service life and high efficiency that lower total project costs.
24/7 global support and flexible customization that adapts to your needs.

Whether you’re drilling in hard granite, soft sedimentary rock, permafrost, or coastal environments, we have the perfect thread drill bit solution. Contact us today to request a sample, get a customized quote, or discuss your project’s specific requirements—let Jiufu be your trusted partner for global drilling success.
